| رقم الطراز: | TXHW98NEW |
| الـ MOQ: | 1 |
| السعر: | $3,750-6,890 |
Shenzhen Outdoor Specialized Display Equipment Co., Ltd. introduces its IP67 waterproof outdoor digital signage, designed specifically for all-weather advertising and information display in harsh outdoor environments. Featuring an IP67 fully sealed protection rating and a high-brightness output of 2500 nits, this product delivers clear and stable visual performance even under conditions involving rain, dust, and direct sunlight.
| Parameter | Specification |
|---|---|
| Protection Rating | IP67 (Completely dustproof + Protection against temporary immersion) |
| Brightness | 2500 nits |
| Display Size | 32-inch / 55-inch (Optional) |
| Resolution | 1920 × 1080 (Full HD) |
| Viewing Angle | 178° (Horizontal/Vertical) |
| Operating Temperature | -20°C ~ 55°C |
| Storage Temperature | -30°C ~ 65°C |
| Panel Type | A-Si TFT-LCD |
| Housing Material | Aluminum Alloy |
| System Support | Android / Windows / Linux |
| Mounting Method | Wall-Mounted (VESA Standard) |
| Net Weight | 32-inch ≈ 28kg / 55-inch ≈ 42kg |
| Color Depth | 16.7M |
| Response Time | 8ms |
| Lifespan | ≥ 50,000 hours |
This IP67 outdoor waterproof display is widely utilized in various settings, including highway service areas, shopping mall entrances, parking lot EV charging stations, commercial district outdoor advertising spaces, and scenic area information kiosks. Its wall-mounted design conserves floor space while maintaining visibility at eye level. The full aluminum alloy housing offers both structural strength and efficient heat dissipation capabilities, making it suitable for use in coastal, tropical, and temperate climatic regions.
Completely prevents dust ingress and offers protection against temporary immersion. Precision silicone sealing strips and waterproof cable connectors ensure zero water penetration for up to 30 minutes at a depth of 1 meter.
A high-power LED backlight array, combined with an optical diffusion film, maintains content contrast and readability even under direct sunlight with ambient light intensities exceeding 100,000 lux.
The A-Si TFT-LCD panel delivers consistent color and brightness across a wide viewing range, ensuring content remains visible from multiple directions.
The aluminum alloy chassis, featuring integrated heat dissipation fins, efficiently conducts internal heat without the need for ventilation vents, thereby maintaining IP67 sealing integrity.
An embedded network module supports remote monitoring, scheduled content updates, and device status inquiries.
